Build
| Frame | Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 6in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Adjustable dropouts, Carrying handle, PowerTube box (lockable) BB Standard: Bosch, Press Fit Color: Stealth Black |
|---|---|
| Fork | SR Suntour Mobie25 LOR, Travel: 63 mm, Coil spring, Lockout, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 6in, Fender mounts Travel: 63mm Spring Type: Coil |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1.8in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/46 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 700 mm, Backsweep: 9, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal ON Male |
| Seatpost | Oxygen E-Scorpo DPR-S-E, Travel: 75 mm | 100 mm, Remote Lockout, Length: 360 mm | 410 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type: Dropper |
| Pedals | ATB Alu Pro Reflex |
Groupset
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
|---|---|
| Shifters | Shimano Nexus-5 Revo, SL-C7000-5, Twist shifter, 5-speed |
| Cassette | Gates CDX Center Track sprocket, 32 T |
| Brakes | Tektro HD-T280, Hydraulic disc brake, 2 pistons Type: Tektro Hydraulic Disc |
| Brake Levers | Tektro HD-T280, 3 finger |
Wheels
| Rims | Oxygen RM-26 Disc, ETRTO: 26 x 622 |
|---|---|
| Front Hub | Strummer RTP-1, Axle: QR15x100 mm |
| Tires | Schwalbe Marathon, Tire size: 47-622, Endurance compound, GreenGuard, Reflective stripes |
Electric Components
| Motor | Bosch G3 Performance Line, The smart system, Continuous rated power: 250 W, Max. torque: 75 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerTube 625, The smart system, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Intuvia 100, The smart system |
| Charger | Bosch 4A charger |
Accessories
| Lights | Front: Trelock Light Hammer 80, Illuminance: 80 lux, Automatic on/off, Daylight function, Rear: B+M Shine Evo, Integrated taillight |
|---|---|
| Fenders | SKS mudguards |
| Racks | Racktime Shine Evo RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
| Bell | STEVENS D85 bell |
