Build
| Frame | Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Adjustable dropouts, Carrying handle BB Standard: Bosch, Press Fit Color: Electric Silver |
|---|---|
| Fork | SR Suntour Mobie34-Air, Travel: 80 mm, Air suspension, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 7in, Fender mounts Travel: 80mm Spring Type: Air |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/40 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 700 mm, Backsweep: 9, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal ON Female |
| Seatpost | Oxygen E-Scorpo, Length: 320 mm, Diameter: 30.9 mm, Insertion depth: min. 100 mm Type: Rigid |
| Pedals | ATB Alu Pro Reflex |
Groupset
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
|---|---|
| Shifters | Enviolo Twist Controller, Twist shifter, With Display |
| Cassette | Gates CDX Center Track sprocket, 24 T |
| Brakes | Shimano CUES U8000, BR-U8020, Hydraulic disc brake, Postmount standard, 4 pistons Type: Shimano Hydraulic Disc |
| Brake Levers | Shimano CUES U8000, 3 finger, I-Spec II |
Wheels
| Rims | Oxygen RM-T25 Disc, ETRTO: 25 x 622 |
|---|---|
| Front Hub | Strummer M17-3, Axle: QR15x100 mm |
| Tires | Schwalbe Marathon Efficiency Evolution, Tire size: 50-622, Foldable, Super Race, ADDIX Race Compound, V-Guard |
Electric Components
| Motor | Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerPack 800, The smart system, Capacity: 800 Wh/22.2 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Kiox 300, The smart system |
| Charger | Bosch 4A charger |
Accessories
| Lights | Front: Supernova Mini 3 Pro, Illuminance: 125 lux, High beam: 150 lux, Close range light, Automatic daylight function, Rear: Supernova M99 TL 3 MAX, Stationary taillight |
|---|---|
| Fenders | SKS mudguards |
| Racks | Racktime Supernova RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
| Bell | STEVENS D85 bell |
