Build
| Frame | Carbon SL HMF, O.L.D.: 148 mm, Brake: postmount disc 7in, BB: Shimano Steps, Cable routing: internal BB Standard: STEPS, Press Fit Color: Deep Blue |
|---|---|
| Fork | Fox 36 Float Performance E-Optimized, Travel: 150 mm, Air suspension, Tapered Steerer 1 1/8in – 1.5in, O.L.D.: 110 mm, Brake: postmount disc 7in Travel: 150mm Spring Type: Air |
| Bottom Bracket | STEPS, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/40 |
| Stem | Oxygen E-Scorpo, Handlebar clamp: 35 mm, Angle: 5 |
| Handlebar | Oxygen E-Scorpo, Width: 780 mm, Backsweep: 9, Rise: 25 mm, Clamp: 35 mm |
| Saddle | Fizik Terra Alpaca |
| Seatpost | Oxygen E-Scorpo DPR-E, Travel: 100 mm | 125 mm | 150 mm, Remote Lockout, Length: 340 mm | 390 mm | 440 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type: Dropper |
| Pedals | MTB Alu Flatpedal Reflex |
Groupset
| Rear Derailleur | Shimano Deore XT Shadow+, RD-M8100-SGS, 12-speed, Total capacity: 41 T |
|---|---|
| Crank | Shimano Steps EP8, FC-EM600, BB type: Shimano Steps |
| Shifters | Shimano Deore XT, SL-M8100-R, 12-speed |
| Cassette | Shimano Deore, CS-M6100, 12-speed, Combination: 10-12-14-16-18-21-24-28-33-39-45-51 T |
| Chain | Shimano CN-M6100 |
| Brakes | Shimano BR-MT520, Hydraulic disc brake, 4 pistons Type: Shimano Hydraulic Disc |
| Brake Levers | Shimano BL-MT501 |
Wheels
| Rims | Sun Ringl Droc SD37, ETRTO: 31 x 622 |
|---|---|
| Front Hub | Strummer CLTP, Axle: QR15x110 mm |
| Rear Hub | Strummer M42-3, Axle: QR12x148 mm |
| Tires | Schwalbe Magic Mary Evolution, Tire size: 65-622, Super Trail, Foldable, ADDIX Soft compound, SnakeSkin, Tubeless Easy |
Electric Components
| Motor | Shimano EP801, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), Mileage: shimano-steps.com, No of notches: 3 optimally graded driving modes plus walk assistance with support level up to 400 %, driving modes: customizable via E-Tube App |
|---|---|
| Battery | Darfon 726, Capacity: 726 Wh/20.0 Ah, Voltage: 36.3 V, Technology: Li-Ion |
| Display | Shimano SC-EM800 |
| Charger | Darfon 4A charger |
