Build
| Frame | Carbon SL HMF, O.L.D.: 148 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal BB Standard: Bosch, Press Fit Color: Blue Black |
|---|---|
| Fork | Fox 36 Float Factory E-Optimized, Travel: 150 mm, Air suspension, Tapered Steerer 1 1/8in – 1.5in, O.L.D.: 110 mm, Brake: postmount disc 7in Travel: 150mm Spring Type: Air |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/40 |
| Stem | Race Face Turbine-R, Handlebar clamp: 35 mm, Angle: 0 |
| Handlebar | Race Face Next-R Carbon, Width: 800 mm, Rise: 35 mm, Clamp: 35 mm |
| Saddle | Fizik Terra Alpaca |
| Seatpost | Fox Transfer Factory, Travel: 125 mm | 150 mm | 175 mm, Remote, Length: 320 mm | 379 mm | 444 mm, Diameter: 30.9 mm, Insertion depth: 80 mm | 85 mm | 92 mm Type: Dropper |
| Pedals | MTB Flatpedal Reflex |
Groupset
| Rear Derailleur | Shimano XTR Shadow+, RD-M9100-SGS, 12-speed, Total capacity: 41 T |
|---|---|
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
| Shifters | Shimano XTR, SL-M9100-R, 12-speed, I-SPEC EV |
| Cassette | Shimano Deore XT, CS-M8100-12, 12-speed, Combination: 10-12-14-16-18-21-24-28-33-39-45-51 T |
| Chain | Shimano CN-M8100 |
| Brakes | Shimano XTR, BR-M9120, Hydraulic disc brake, 4 pistons Type: Shimano XTR Hydraulic Disc |
| Brake Levers | Shimano BL-M9120, 2 finger |
Wheels
| Rims | Race Face Next-R 36 Carbon, Axle: QR15x110 mm |
|---|---|
| Tires | Schwalbe Magic Mary Evolution, Tire size: 65-622, Super Trail, Foldable, ADDIX Soft compound, SnakeSkin, Tubeless Easy |
Electric Components
| Motor | Bosch G4 Performance Line CX Race, Limited edition, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), Exclusive Race mode, No of notches: 4 drive modes with support levels 60-400 % plus walk assistance, Hill hold function, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerTube 750, The smart system, Capacity: 750 Wh/20.1 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Kiox 300, The smart system |
| Charger | Bosch 4A charger |
