Build
Frame |
Aluminium 6061 TB, O.L.D.: 148 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal BB Standard:Â Bosch, Press Fit Color:Â Chrome Black |
---|---|
Fork |
RockShox 35 Gold RL, Travel: 120 mm, Air suspension, Tapered Steerer 1 1/8in – 1.8”, O.L.D.: 110 mm, Brake: postmount disc 7in, Lockout Travel:Â 120mm Spring Type:Â Air |
Bottom Bracket |
Bosch, press-fit |
Headset |
Acros Blocklock Taper 1 1/8in-1.8in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/46 |
Stem |
Oxygen E-Scorpo, Handlebar clamp: 35 mm, Angle: 5 |
Handlebar |
Oxygen E-Scorpo, Width: 750 mm, Backsweep: 9, Rise: 25 mm, Clamp: 35 mm |
Saddle |
Fizik Terra Aidon X5 |
Seatpost |
Oxygen E-Scorpo DPR-E, Travel: 125 mm | 150 mm, Remote Lockout, Length: 390 mm | 440 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type:Â Dropper |
Pedals |
MTB Flatpedal Reflex |
Groupset
Rear Derailleur |
Shimano Deore XT Shadow+, RD-M8130-SGS, 11-speed, Total capacity: 39 T |
---|---|
Crank |
Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
Shifters |
Shimano CUES U6000, SL-U6000-11R, 11-speed |
Cassette |
Shimano CS-LG400-11, 11-speed, Combination: 11-13-15-17-20-23-26-30-36-43-50 T |
Chain |
Shimano CN-LG500, LINKGLIDE |
Brakes |
Shimano BR-MT420, Hydraulic disc brake, 4 pistons Type:Â Shimano Hydraulic Disc |
Brake Levers |
Shimano BL-MT401, 2 finger, Aluminium lever |
Wheels
Rims |
Sun Ringl Droc TR35, ETRTO: 31 x 622 |
---|---|
Front Hub |
Strummer CLTP, Axle: QR15x110 mm |
Rear Hub |
Strummer CLTP-1, Axle: QR12x148 mm |
Tires |
Schwalbe Johnny Watts Performance, Tire size: 60-622, Foldable, ADDIX compound, RaceGuard, SnakeSkin, Double Defense, Reflective stripes |
Electric Components
Motor |
Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
---|---|
Battery |
Bosch PowerTube 625, The smart system, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion |
Display |
Bosch Kiox 500, The smart system |
Charger |
Bosch 4A charger |
Accessories
Lights |
Front: Supernova Mini 3 Pro, Illuminance: 125 lux, High beam: 150 lux, Close range light, Automatic daylight function, Rear: Supernova TL 3 Z, Stationary taillight |
---|---|
Fenders |
Curana Apollo mudguards |
Racks |
STEVENS RC QL3.1, QL3.1 Mounting system |
Bell |
STEVENS D85 bell |
