Build
| Frame | Aluminium 6061 TB, O.L.D.: 148 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal BB Standard: STEPS, Press Fit Color: Polar Blue |
|---|---|
| Fork | Fox 34 Float eMTB+ AWL, Travel: 120 mm, Air suspension, Tapered Steerer 1 1/8in – 1.5in, O.L.D.: 110 mm, Brake: postmount disc 6in Travel: 120mm Spring Type: Air |
| Bottom Bracket | STEPS, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1.8in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/46 |
| Stem | Oxygen E-Scorpo, Handlebar clamp: 35 mm, Angle: 5 |
| Handlebar | Oxygen E-Scorpo, Width: 750 mm, Backsweep: 9, Rise: 25 mm, Clamp: 35 mm |
| Saddle | Fizik Terra Aidon X5 |
| Seatpost | Oxygen E-Scorpo DPR-E, Travel: 100 mm | 125 mm | 150 mm, Remote Lockout, Length: 340 mm | 390 mm | 440 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type: Dropper |
| Pedals | MTB Alu Flatpedal Reflex |
Groupset
| Rear Derailleur | Shimano Deore XT Shadow+, RD-M8130-SGS, 11-speed, Total capacity: 39 T |
|---|---|
| Crank | Shimano Steps EP8, FC-EM600, BB type: Shimano Steps |
| Shifters | Shimano Deore XT, SL-M8130-R, 11-speed, I-SPEC EV |
| Cassette | Shimano CS-LG700-11, 11-speed, Combination: 11-13-15-17-20-23-26-30-36-43-50 T |
| Chain | KMC e11S EPT |
| Brakes | Shimano Deore XT, BR-M8120, Hydraulic disc brake, 4 pistons Type: Shimano XT Hydraulic Disc |
| Brake Levers | Shimano BL-T8100 |
Wheels
| Rims | DT Swiss H 1900 Spline, Axle: QR15x110 mm |
|---|---|
| Tires | Schwalbe Johnny Watts Performance, Tire size: 60-622, Foldable, ADDIX compound, RaceGuard, SnakeSkin, Double Defense, Reflective stripes |
Electric Components
| Motor | Shimano EP800, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), Mileage: shimano-steps.com, No of notches: 3 optimally graded driving modes plus walk assistance with support level up to 400 %, driving modes: customizable via E-Tube App |
|---|---|
| Battery | Darfon 726, Capacity: 726 Wh/20.0 Ah, Voltage: 36.3 V, Technology: Li-Ion |
| Display | Shimano SC-EM800 |
| Charger | Darfon 4A charger |
Accessories
| Lights | Front: B+M IQ-XL, Illuminance: 300 lux, 11 watt, High beam: 250 lux, 16 watt, Daylight function, Rear: B+M Ilu mini, Integrated taillight |
|---|---|
| Fenders | Curana Apollo mudguards |
| Racks | STEVENS RC QL3.1, QL3.1 Mounting system |
| Bell | STEVENS D85 bell |
