Build
| Frame | Carbon SL HMF, O.L.D.: 148 mm, Brake: Postmount-Disc 180, Tretlager: TQ, Zugverlegung: intern Color: Lavender Grey |
|---|---|
| Fork | Fox 36 Float Performance Elite eMTB+, Travel: 160 mm, Air suspension, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 110 mm, Brake: postmount disc 7in Travel: 160mm Spring Type: Air |
| Headset | Acros Blocklock Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS56/40 |
| Stem | Race Face Turbine-R, Handlebar clamp: 35 mm, Angle: 0 |
| Handlebar | Race Face Turbine, Width: 800 mm, Rise: 20 mm, Clamp: 35 mm |
| Saddle | Fizik Terra Alpaca |
| Seatpost | Oxygen E-Scorpo DPR-E, Travel: 125 mm | 150 mm | 170 mm, Remote Lockout, Length: 390 mm | 440 mm | 480 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type: Dropper |
| Pedals | MTB Flatpedal Reflex |
Groupset
| Rear Derailleur | Shimano Deore XT Shadow+, RD-M8100-SGS, 12-speed, Total capacity: 41 T |
|---|---|
| Crank | FSA CK-9011/IS, Super light weight aluminum, BB type: ISIS, Crank bolt with QR-32 |
| Shifters | Shimano Deore XT, SL-M8100-R, 12-speed |
| Cassette | Shimano SLX, CS-M7100, 12-speed, Combination: 10-12-14-16-18-21-24-28-33-39-45-51 T |
| Chain | Shimano CN-M6100 |
| Brakes | Shimano Deore XT, BR-MT8120, Hydraulic disc brake, 4 pistons Type: Shimano XT Hydraulic Disc |
| Brake Levers | Shimano Deore XT, BL-M8100, 2 finger |
Wheels
| Rims | DT Swiss HX 1700 Spline, Axle: QR15x110 mm, Tubeless ready |
|---|---|
| Tires | Schwalbe Magic Mary Evolution, Tire size: 62-622, Super Trail, Foldable, ADDIX Soft compound, SnakeSkin, Tubeless Easy |
Electric Components
| Motor | TQ HPR50, Continuous rated power: 300 W, Max. torque: 50 Nm, Breakaway at 25 km/h (15.5 mph) |
|---|---|
| Battery | TQ HPR-BAT01, Kapazitt: 360 Wh/6.8 Ah, Voltage: 50.4 V, Technology: Li-Ion |
| Display | TQ HPR Display |
| Charger | TQ 4A charger |
