Build
| Frame | Aluminium 6061, O.L.D.: 135 mm, Brake: IS disc, BB: Bosch, Cable routing: internal, Fender + rack mounts BB Standard: Bosch, Press Fit Colors: Polar Petrol; Velvet Black |
|---|---|
| Fork | SR Suntour NX1-Coil LO, Travel: 63 mm, Coil spring, Lockout, Steerer 1 1/8in, O.L.D.: 100 mm, Brake: postmount disc 6in, Fender mounts Travel: 63mm Spring Type: Coil |
| Bottom Bracket | Bosch, press-fit |
| Headset | STEVENS AH 1 1/8in, Upper bearing cup: ZS44/28.6, Lower bearing cup: ZS44/30 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal Nuvola Lady |
| Seatpost | Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm Type: Rigid |
| Pedals | City Reflex |
Groupset
| Rear Derailleur | Sunrace RDM93, 8/9-speed, Total capacity: 40 T |
|---|---|
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
| Shifters | Sunrace DLM903, 9-speed |
| Cassette | SunRace CSM90, 9-speed, Combination: 11-13-15-17-20-23-26-30-36 T |
| Chain | KMC X9 NPGY |
| Brakes | Tektro HD-T280, Hydraulic disc brake, 2 pistons Type: Tektro Hydraulic Disc |
| Brake Levers | Tektro HD-T280, 3 finger |
Wheels
| Rims | Oxygen RM-26 Disc, ETRTO: 26 x 622 |
|---|---|
| Front Hub | Formula CL-51, Axle: QR5x100 mm |
| Rear Hub | Formula CL-52, Axle: QR5x135 mm |
| Tires | Schwalbe Marathon, Tire size: 47-622, Endurance compound, GreenGuard, Reflective stripes |
Electric Components
| Motor | Bosch G3 Active Line, Continuous rated power: 250 W, Max. torque: 40 Nm, Breakaway at 25 km/h (15.5 mph), Mileage: See BOSCH Range Assistant, No of notches: 4 drive modes with support levels 40-250 % plus walk assistance |
|---|---|
| Battery | Bosch PowerPack 400, Capacity: 400 Wh/11.0 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Purion |
| Charger | Bosch 2A charger |
Accessories
| Lights | Front: AXA Compactline 35, Illuminance: 35 lux, Rear: AXA Blueline, Stationary taillight |
|---|---|
| Fenders | SKS mudguards |
| Racks | STEVENS rear rack, System: SNAP IT |
| Bell | STEVENS D85 bell |
