Description

Build

Frame

Aluminium 6061, O.L.D.: 135 mm, Brake: Flatmount disc 6in, BB: Pressfit BB86, Cable routing: internal (shifting)/external (brake), Fender + rack mounts

BB Standard: BB86/BB92, Press Fit

Color: Ivy Green

Fork

STEVENS S-Lite Aluminium, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: Flatmount 6in, Fender mounts

Travel: 100mm

Bottom Bracket

BB86/BB92, press-fit

Headset

Acros Viper Taper 1 1/8in-1,5in, Upper bearing cup: ZS52/28.6, Lower bearing cup: ZS52/40

Stem

Oxygen E-Scorpo, Handlebar clamp: 31.8 mm, Angle: -7

Handlebar

Oxygen E-Scorpo, Width: 640 mm, Backsweep: 9, Rise: 12.7 mm, Clamp: 31.8 mm

Saddle

Selle Royal Vivo Ergo Sport

Seatpost

LightSKIN LED Alloy, Length: 350 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm, Integrated taillight, 5 LEDs

Type: Rigid

Pedals

ATB Alu Comp Reflex

Groupset

Rear Derailleur

Shimano 105 Shadow, RD-R7000-SS, 11-speed, Total capacity: 35 T

Front Derailleur

Shimano 105, FD-R7000-FL, 2-speed

Crank

Shimano RS510, 50-34 T, BB type: Pressfit BB86 / 2-Piece

Shifters

Shimano SL-RS700, 2-speed

Cassette

Shimano 105, CS-R7000, 11-speed, Combination: 11-12-13-14-15-17-19-21-24-27-30 T

Chain

KMC X11 EPT

Brakes

Shimano BR-RS405, Hydraulic disc brake

Type: Shimano Hydraulic Disc

Brake Levers

Shimano BL-RS600

Wheels

Rims

Fulcrum E-Racing 900 DB, Axle: QR12x100 mm

Tires

Schwalbe G-One Allround Performance, Tire size: 40-622, ADDIX compound, RaceGuard

Electric Components

Motor

Mahle X30 Hub Engine, Continuous rated power: 250 W, Max. torque: comparable to 44 Nm mid-drive, Breakaway at 25 km/h (15.5 mph)

Battery

Mahle iX2, Kapazitt: 236 Wh/6.6 Ah, Voltage: 36 V, Technology: Li-Ion

Charger

Mahle 4A charger

Accessories

Lights

Front: Supernova Mini 2, Illuminance: 100 lux, Close range light, Daylight function

Fenders

Curana Apollo mudguards

Racks

Racktime RTA rear rack, Rear rack mount: RTA, System: SNAP IT 2.0, QL3.1 system

Bell

STEVENS D85 bell
