Build
| Frame | Aluminium 6061, O.L.D.: 136.5 mm, Brake: Flatmount disc 6in, BB: Pinion, Cable routing: internal, Fender + rack mounts, Adjustable dropouts, Bolted seatstay (drive side) BB Standard: Pinion, Press Fit Color: Vogue Silver |
|---|---|
| Fork | STEVENS S-Lite Aluminium, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: Flatmount 6in, Fender mounts Travel: 100mm |
| Bottom Bracket | Pinion, press-fit |
| Headset | Acros Viper Taper 1 1/8in-1,5in, Upper bearing cup: ZS52/28.6, Lower bearing cup: ZS52/40 |
| Stem | Oxygen E-Scorpo, Handlebar clamp: 31.8 mm, Angle: -7 |
| Handlebar | Oxygen E-Scorpo, Width: 640 mm, Backsweep: 9, Rise: 12.7 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal Vivo Ergo Sport |
| Seatpost | LightSKIN LED Alloy, Length: 350 mm, Diameter: 27.2 mm, Insertion depth: min. 100 mm, Integrated taillight, 5 LEDs Type: Rigid |
| Pedals | ATB Alu Comp Reflex |
Groupset
| Crank | Gates CDX chainring, 39 T |
|---|---|
| Shifters | Pinion 9-spd twist shifter |
| Cassette | Gates CDX Center Track sprocket, 30 T |
| Brakes | Shimano BR-RS405, Hydraulic disc brake Type: Shimano Hydraulic Disc |
| Brake Levers | Shimano BL-RS600 |
Wheels
| Rims | Fulcrum E-Racing 900 DB, Axle: QR12x100 mm |
|---|---|
| Tires | Schwalbe G-One Allround Performance, Tire size: 40-622, Foldable, RaceGuard, ADDIX Compound, Tubeless Easy, Reflective stripes |
Electric Components
| Motor | Mahle X30 Hub Engine, Continuous rated power: 250 W, Max. torque: comparable to 44 Nm mid-drive, Breakaway at 25 km/h (15.5 mph) |
|---|---|
| Battery | Mahle iX2, Kapazitt: 236 Wh/6.6 Ah, Voltage: 36 V, Technology: Li-Ion |
| Charger | Mahle 4A charger |
Accessories
| Lights | Front: Supernova Mini 2, Illuminance: 100 lux, Close range light, Daylight function |
|---|---|
| Fenders | Curana Apollo mudguards |
| Racks | Racktime RTA rear rack, Rear rack mount: RTA, System: SNAP IT 2.0, QL3.1 system |
| Bell | STEVENS D85 bell |
