Build
| Frame | Aluminium 6061, O.L.D.: 135 mm, Brake: postmount disc 6in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Carrying handle, PowerTube box (lockable) BB Standard: Bosch, Press Fit Color: Velvet Black |
|---|---|
| Fork | SR Suntour Mobie25-Air LOR, Travel: 63 mm, Air suspension, Lockout, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 6in, Fender mounts Travel: 63mm Spring Type: Air |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1.8in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/46 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 700 mm, Backsweep: 9, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal ON Male |
| Seatpost | Oxygen E-Scorpo, Length: 320 mm, Diameter: 30.9 mm, Insertion depth: min. 100 mm Type: Rigid |
| Pedals | ATB Alu Pro Reflex |
Groupset
| Rear Derailleur | Shimano CUES U6000 Shadow+, RD-U6000-GS, 10/11-speed, Total capacity: 39 T |
|---|---|
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS |
| Shifters | Shimano CUES U6000, SL-U6000-10R, 10-speed |
| Cassette | Shimano CS-LG300-10, 10-speed, Combination: 11-13-15-17-20-23-28-34-41-48 T |
| Chain | Shimano CN-LG500, LINKGLIDE |
| Brakes | Tektro Volans, HD-T532-F, Hydraulic disc brake, 4 pistons Type: Tektro Volans Hydraulic Disc |
| Brake Levers | Tektro HD-T532, 3 finger |
Wheels
| Rims | Oxygen RM-26 Disc SL, ETRTO: 26 x 622 |
|---|---|
| Front Hub | Strummer RTP-1, Axle: QR15x100 mm |
| Rear Hub | Formula CL-26, Axle: QR9x135 mm |
| Tires | Schwalbe Marathon Performance, Tire size: 50-622, ADDIX compound, TwinSkin, GreenGuard, Reflective stripes |
Electric Components
| Motor | Bosch G3 Performance Line, The smart system, Continuous rated power: 250 W, Max. torque: 75 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerTube 625, The smart system, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Intuvia 100, The smart system |
| Charger | Bosch 4A charger |
Accessories
| Lights | Front: B+M IQ-XS Friendly, Illuminance: 80 lux, Close range light, Daylight function, Rear: B+M Shine Evo, Integrated taillight |
|---|---|
| Fenders | SKS mudguards |
| Racks | Racktime Shine Evo RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
| Bell | STEVENS D85 bell |
