Build
| Frame | Aluminium 6061, O.L.D.: 142 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Carrying handle, PowerTube box (lockable) BB Standard: Bosch, Press Fit Colors: Glacier Blue; Deep Green |
|---|---|
| Fork | SR Suntour Mobie25-Air LOR, Travel: 63 mm, Air suspension, Lockout, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 6in, Fender mounts Travel: 63mm Spring Type: Air |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1.8in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/46 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal ON Female |
| Seatpost | Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm Type: Rigid |
| Pedals | ATB Alu Pro Reflex |
Groupset
| Rear Derailleur | Shimano Deore Shadow+, RD-M5120-SGS, 10/11-speed, Total capacity: 41 T |
|---|---|
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
| Shifters | Shimano Deore, SL-M5100, 11-speed |
| Cassette | SunRace CSMS8, 11-speed, Combination: 11-13-15-17-19-21-24-28-32-37-42 T |
| Chain | Shimano CN-HG601 |
| Brakes | Tektro Volans, HD-T532-F, Hydraulic disc brake, 4 pistons Type: Tektro Volans Hydraulic Disc |
| Brake Levers | Tektro HD-T532, 3 finger |
Wheels
| Rims | Oxygen RM-26 Disc SL, ETRTO: 26 x 622 |
|---|---|
| Front Hub | Shimano Deore XT, HB-M8010, Axle: QR15x100 mm |
| Rear Hub | Shimano Deore XT, FH-M8010, Axle: QR12x142 mm |
| Tires | Schwalbe Marathon E-Plus Performance, Tire size: 50-622, ADDIX E compound, SmartGuard, Reflective stripes |
Electric Components
| Motor | Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerTube 625, The smart system, Capacity: 625 Wh/16.7 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Kiox 300, The smart system |
| Charger | Bosch 4A charger |
Accessories
| Lights | Front: B+M IQ-XS Friendly, Illuminance: 80 lux, Close range light, Daylight function, Rear: B+M Shine Evo, Integrated taillight |
|---|---|
| Fenders | SKS mudguards |
| Racks | Racktime Shine Evo RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
| Bell | STEVENS D85 bell |
