Build
Frame |
Aluminium 6061, O.L.D.: 142 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Carrying handle, PowerTube box (lockable) BB Standard:Â Bosch, Press Fit Colors:Â Deep Green; Glacier Blue |
---|---|
Fork |
SR Suntour Mobie34-Air, Travel: 80 mm, Air suspension, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 7in, Fender mounts Travel:Â 80mm Spring Type:Â Air |
Bottom Bracket |
Bosch, press-fit |
Headset |
Acros Blocklock Taper 1 1/8in-1.8in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/46 |
Stem |
Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
Handlebar |
Oxygen E-Scorpo, Width: 700 mm, Backsweep: 9, Rise: 25 mm, Clamp: 31.8 mm |
Saddle |
Selle Royal ON Female |
Seatpost |
Oxygen E-Scorpo, Length: 320 mm, Diameter: 30.9 mm, Insertion depth: min. 100 mm Type:Â Rigid |
Pedals |
ATB Alu Pro Reflex |
Groupset
Rear Derailleur |
Shimano CUES U8000 Shadow+, RD-U8000-GS, 11-speed, Total capacity: 39 T |
---|---|
Crank |
Oxygen E-Scorpo, BB type: Bosch / ISIS |
Shifters |
Shimano CUES U6000, SL-U6000-11R, 11-speed |
Cassette |
Shimano CS-LG400-11, 11-speed, Combination: 11-13-15-17-20-23-26-30-36-43-50 T |
Chain |
Shimano CN-LG500, LINKGLIDE |
Brakes |
Tektro Volans, HD-T532-F, Hydraulic disc brake, 4 pistons Type:Â Tektro Volans Hydraulic Disc |
Brake Levers |
Tektro HD-T532, 3 finger |
Wheels
Rims |
Oxygen RM-26 Disc SL, ETRTO: 26 x 622 |
---|---|
Front Hub |
Strummer G15-3, Axle: QR15x100 mm |
Rear Hub |
Strummer M42-3, Axle: QR12x148 mm |
Tires |
Schwalbe Marathon E-Plus Performance, Tire size: 50-622, ADDIX E compound, SmartGuard, Reflective stripes |
Electric Components
Motor |
Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
---|---|
Battery |
Bosch PowerPack 725, The smart system, Capacity: 725 Wh/19.2 Ah, Voltage: 36 V, Technology: Li-Ion |
Display |
Bosch Kiox 300, The smart system |
Charger |
Bosch 4A charger |
Accessories
Lights |
Front: B+M IQ-XS Friendly, Illuminance: 80 lux, Close range light, Daylight function, Rear: B+M Shine Evo, Integrated taillight |
---|---|
Fenders |
SKS mudguards |
Racks |
Racktime Shine Evo RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
Bell |
STEVENS D85 bell |
