Build
| Frame | Aluminium 6061, O.L.D.: 148 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Carrying handle BB Standard: Bosch, Press Fit Color: Urban Grey |
|---|---|
| Fork | SR Suntour Mobie34-Air LOR, Travel: 80 mm, Air suspension, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 7in, Fender mounts Travel: 80mm Spring Type: Air |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/40 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal ON Female |
| Seatpost | Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm Type: Rigid |
| Pedals | ATB Alu Pro Reflex |
Groupset
| Rear Derailleur | Shimano Deore XT Shadow+, RD-M8100-SGS, 12-speed, Total capacity: 41 T |
|---|---|
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS |
| Shifters | Shimano Deore XT, SL-M8100-R, 12-speed |
| Cassette | Shimano Deore XT, CS-M8100-12, 12-speed, Combination: 10-12-14-16-18-21-24-28-33-39-45-51 T |
| Chain | Shimano CN-M8100 |
| Brakes | Magura MT C ABS, Hydraulic disc brake, 4 pistons, ABS Type: Magura Hydraulic Disc |
| Brake Levers | Magura CMe5, 3 finger |
Wheels
| Rims | Oxygen RM-T25 Disc, ETRTO: 25 x 622 |
|---|---|
| Front Hub | Strummer M17-3, Axle: QR15x100 mm |
| Rear Hub | Strummer M42-3, Axle: QR12x148 mm |
| Tires | Schwalbe Marathon Efficiency Evolution, Tire size: 50-622, Foldable, Super Race, ADDIX Race Compound, V-Guard |
Electric Components
| Motor | Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerPack 725, The smart system, Capacity: 725 Wh/19.2 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Kiox 300, The smart system |
| Charger | Bosch 4A charger |
Accessories
| Lights | Front: B+M IQ-XM, Illuminance: 120 lux, High beam: 170 lux, Close range light, Rear: Supernova M99 TL 3 MAX, Stationary taillight |
|---|---|
| Fenders | SKS mudguards |
| Racks | Racktime Supernova RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
| Bell | STEVENS D85 bell |
