Build
Frame |
Aluminium 6061, O.L.D.: 148 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal, Fender + rack mounts, Carrying handle BB Standard:Â Bosch, Press Fit Color:Â Urban Grey |
---|---|
Fork |
SR Suntour Mobie34-Air LOR, Travel: 80 mm, Air suspension, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 7in, Fender mounts Travel:Â 80mm Spring Type:Â Air |
Bottom Bracket |
Bosch, press-fit |
Headset |
Acros Blocklock Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/40 |
Stem |
Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
Handlebar |
Oxygen E-Scorpo, Width: 680 mm, Backsweep: 5, Rise: 25 mm, Clamp: 31.8 mm |
Saddle |
Selle Royal ON Male |
Seatpost |
Oxygen E-Scorpo, Length: 320 mm, Diameter: 30,9 mm, Insertion depth: min. 100 mm Type:Â Rigid |
Pedals |
ATB Alu Pro Reflex |
Groupset
Rear Derailleur |
Shimano Deore XT Shadow+, RD-M8100-SGS, 12-speed, Total capacity: 41 T |
---|---|
Crank |
Oxygen E-Scorpo, BB type: Bosch / ISIS |
Shifters |
Shimano Deore XT, SL-M8100-R, 12-speed |
Cassette |
Shimano Deore XT, CS-M8100-12, 12-speed, Combination: 10-12-14-16-18-21-24-28-33-39-45-51 T |
Chain |
Shimano CN-M8100 |
Brakes |
Magura MT C ABS, Hydraulic disc brake, 4 pistons, ABS Type:Â Magura Hydraulic Disc |
Brake Levers |
Magura CMe5, 3 finger |
Wheels
Rims |
Oxygen RM-T25 Disc, ETRTO: 25 x 622 |
---|---|
Front Hub |
Strummer M17-3, Axle: QR15x100 mm |
Rear Hub |
Strummer M42-3, Axle: QR12x148 mm |
Tires |
Schwalbe Marathon Efficiency Evolution, Tire size: 50-622, Foldable, Super Race, ADDIX Race Compound, V-Guard |
Electric Components
Motor |
Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
---|---|
Battery |
Bosch PowerPack 725, The smart system, Capacity: 725 Wh/19.2 Ah, Voltage: 36 V, Technology: Li-Ion |
Display |
Bosch Kiox 300, The smart system |
Charger |
Bosch 4A charger |
Accessories
Lights |
Front: B+M IQ-XM, Illuminance: 120 lux, High beam: 170 lux, Close range light, Rear: Supernova M99 TL 3 MAX, Stationary taillight |
---|---|
Fenders |
SKS mudguards |
Racks |
Racktime Supernova RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
Bell |
STEVENS D85 bell |
