Build
| Frame | Aluminium 6061 DB, O.L.D.: 142 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal BB Standard: Bosch, Press Fit Color: Deep Green |
|---|---|
| Fork | SR Suntour Mobie25-Air LOR, Travel: 100 mm, Air suspension, Lockout, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 6in Travel: 100mm Spring Type: Air |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1.8in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/46 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 700 mm, Backsweep: 9, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal ON Male |
| Seatpost | Oxygen E-Scorpo DPR-S-E, Travel: 75 mm | 100 mm, Suspension Seatpost, Remote Lockout, Length: 360 mm | 410 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type: Suspension |
| Pedals | MTB Alu Flatpedal Reflex |
Groupset
| Rear Derailleur | Shimano Deore Shadow+, RD-M5120-SGS, 10/11-speed, Total capacity: 41 T |
|---|---|
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS, Chainguard |
| Shifters | Sunrace DLMS33, 10-speed |
| Cassette | SunRace CSMX3, 10-speed, Combination: 11-13-15-18-21-24-28-32-37-42 T |
| Chain | Shimano CN-HG54 |
| Brakes | Tektro HD-M535, Hydraulic disc brake, 4 pistons Type: Tektro Gemini Hydraulic Disc |
| Brake Levers | Tektro HD-M530, 2 finger |
Wheels
| Rims | Oxygen RM-26 Disc, ETRTO: 26 x 622 |
|---|---|
| Front Hub | Shimano MT400, Axle: QR15x100 mm |
| Rear Hub | Strummer RTP-1, Axle: QR12x142 mm |
| Tires | Continental eRuban Plus, Tire size: 54-622, Pure-Grip Compound, Reflective stripes |
Electric Components
| Motor | Bosch G3 Performance Line, The smart system, Continuous rated power: 250 W, Max. torque: 75 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerTube 500, Capacity: 500 Wh/13.4 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Intuvia 100, The smart system |
| Charger | Bosch 4A charger |
Accessories
| Lights | Front: B+M IQ Myc Friendly, Illuminance: 50 lux, Close range light, Daylight function, Rear: B+M Shine Evo, Integrated taillight |
|---|---|
| Fenders | Curana Apollo mudguards |
| Racks | Racktime Shine Evo RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
| Bell | STEVENS D85 bell |
