Build
| Frame | Aluminium 6061 DB, O.L.D.: 148 mm, Brake: postmount disc 7in, BB: Bosch, Cable routing: internal BB Standard: Bosch, Press Fit Color: Honey Brown |
|---|---|
| Fork | SR Suntour Mobie34-Air, Travel: 100 mm, Air suspension, Tapered Steerer 1 1/8in – 1 1/2in, O.L.D.: 100 mm, Brake: postmount disc 7in, Fender mounts Travel: 100mm Spring Type: Air |
| Bottom Bracket | Bosch, press-fit |
| Headset | Acros Blocklock Taper 1 1/8in-1 1/2in, Upper bearing cup: ZS56/28.6, Lower bearing cup: ZS66/40 |
| Stem | Oxygen Versa II, adjustable, Handlebar clamp: 31.8 mm, Angle: adjustable (0 – 90) |
| Handlebar | Oxygen E-Scorpo, Width: 700 mm, Backsweep: 9, Rise: 25 mm, Clamp: 31.8 mm |
| Saddle | Selle Royal ON Male |
| Seatpost | Oxygen E-Scorpo DPR-S-E, Travel: 75 mm | 100 mm, Suspension Seatpost, Remote Lockout, Length: 360 mm | 410 mm, Diameter: 30.9 mm, Insertion depth: 100 mm Type: Suspension |
| Pedals | MTB Alu Flatpedal Reflex |
Groupset
| Rear Derailleur | Shimano Deore XT Shadow+, RD-M8130-SGS, 11-speed, Total capacity: 39 T |
|---|---|
| Crank | Oxygen E-Scorpo, BB type: Bosch / ISIS |
| Shifters | Shimano Deore XT, SL-M8130-R, 11-speed, I-SPEC EV |
| Cassette | Shimano CS-LG700-11, 11-speed, Combination: 11-13-15-17-20-23-26-30-36-43-50 T |
| Chain | KMC e11T |
| Brakes | Tektro HD-T737, Hydraulic disc brake, 4 pistons Type: Tektro Dorado Hydraulic Disc |
| Brake Levers | Tektro HD-T737, 3 finger |
Wheels
| Rims | Oxygen RM-T25 Disc, ETRTO: 25 x 622 |
|---|---|
| Front Hub | Strummer G15-3, Axle: QR15x100 mm |
| Rear Hub | Strummer M42-3, Axle: QR12x148 mm |
| Tires | Continental eRuban Plus, Tire size: 54-622, Pure-Grip Compound, Reflective stripes |
Electric Components
| Motor | Bosch G4 Performance Line CX, The smart system, Continuous rated power: 250 W, Max. torque: 85 Nm, Breakaway at 25 km/h (15.5 mph), No of notches: 4 drive modes with support levels 60-340 % plus walk assistance, Mileage: See BOSCH Range Assistant |
|---|---|
| Battery | Bosch PowerPack 725, The smart system, Capacity: 725 Wh/19.2 Ah, Voltage: 36 V, Technology: Li-Ion |
| Display | Bosch Kiox 300, The smart system |
| Charger | Bosch 4A charger |
Accessories
| Lights | Front: Supernova M99 Mini Pro-25, Illuminance: 150 lux, High beam: 260 lux, Close range light, Daylight function, Rear: Supernova M99 TL 2 Pure, Stationary taillight |
|---|---|
| Fenders | Curana Apollo mudguards |
| Racks | Racktime Supernova RTA rear rack, Rear rack mount: RTA, System: SNAP IT |
| Bell | STEVENS D85 bell |
