Build
Frame |
Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg Color:Â Forge Grey |
---|---|
Fork |
Suntour custom for Tern, 1.5in tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg Travel:Â 70mm |
Bottom Bracket |
Motor integrated |
Headset |
Tern Flux Pro Taper, 1.5in, angular contact bearings, Physis integrated |
Stem |
Tern Andros, adjustable, forged construction, patented technology |
Handlebar |
Tern Sweep, 6061-AL, Tern Andros adapted |
Saddle |
Tern GSD by Velo, with rear handle |
Seatpost |
Cane Creek Thudbuster G4, Tern Telescope, 34.9/30.9 mm Type:Â Rigid |
Pedals |
Urban with non-slip surface, sealed bearings |
Groupset
Crank |
Tern GSD custom, Gates CDX CNC machined beltring |
---|---|
Shifters |
Rohloff E14, e-shift 14 spd |
Cassette |
Gates CDX, precision CNC machined cog |
Chain |
Gates Carbon Drive CDX belt |
Chain Guide |
Tern Custom, full chain cover |
Brakes |
Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads Type:Â Magura MT5 Hydraulic Disc |
Brake Levers |
Magura MT5 e-stop, hydraulic, with brake sensor |
Wheels
Rims |
Tern Atlas, ultra wide 36 mm, dual reinforced joint |
---|---|
Front Hub |
Tern Atlas, Boost Thru-Axle, Cargo-optimized design, sealed cartridge bearing |
Rear Hub |
Rohloff E14, 526% range, Boost |
Tires |
F: Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex R: Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex |
Electric Components
Motor |
Class 1, Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US) |
---|---|
Battery |
Bosch Dual Battery system, 500 Wh or 1000 Wh Recycling Program:Â Â Call2Recycle |
Display |
Bosch Intuvia, Rohloff integrated shifting w/ auto downshift |
Charger |
220V, 4A (EU); 100-240V, 4A (US) |
Accessories
Lights |
Ignis Headlight, Ultra wide 700 lumens, Hi/Lo Beam |
---|---|
Fenders |
Integrated Wheel Guard, AL6061, w/ Side Skirt |
Racks |
Combo Mount |
