Build
| Frame | Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 180 kg Colors: Orange; Satin Black |
|---|---|
| Fork | Suntour custom for Tern, 1.5in tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 180 kg Travel: 70mm |
| Bottom Bracket | Motor integrated |
| Headset | Tern Flux Pro Taper by FSA, 1.5in, angular contact bearings, Physis integrated |
| Stem | Tern Andros, adjustable, forged construction, patented technology |
| Handlebar | Tern Sweep, 6061-AL, Tern Andros adapted |
| Saddle | Tern Upright by Velo |
| Seatpost | Tern Telescope, 34.9/30.9 mm, 2014-AL Type: Rigid |
| Pedals | Urban with non-slip surface |
Groupset
| Rear Derailleur | Shimano Deore Shadow+ |
|---|---|
| Crank | Tern HSD custom |
| Shifters | Shimano Deore, 1 x 10 spd, trigger |
| Cassette | Shimano 11-36T, 10 spd |
| Chain | KMC 10 spd, for eBike, EPT corrosion resistant coating |
| Chain Guide | Tern Custom, full chain cover |
| Brakes | Tektro, hydraulic disc, 180 mm rotor Type: Tektro Hydraulic Disc |
| Brake Levers | Tektro, hydraulic disc |
Wheels
| Rims | Tern Atlas H, wide 35 mm |
|---|---|
| Front Hub | Novatec, Thru-axle, sealed bearings |
| Rear Hub | Novatec, sealed cartridge bearing, disc |
| Tires | Schwalbe Big Apple, 55-406, puncture protection, Reflex |
Electric Components
| Motor | Bosch Performance, 340% Assist, 75 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US) |
|---|---|
| Battery | Bosch PowerPack 545 Recycling Program: Call2Recycle |
| Display | Bosch Intuvia 100 w/ LED remote, 4 mode selectable, walk assist, connectivity with Bosch eBike Flow app, electronic bike lock |
| Charger | 220V, 4A (EU); 100-240V, 4A (US) |
Accessories
| Lights | Tern Valo Direct, 190 lumens |
|---|---|
| Fenders | SKS, stainless hardware |
| Racks | Combo Mount |
| Lock | Optional |
