Build
| Frame | Aluminium 6061 TFW, Motor mount: Bosch, Cable routing: partially integrated, Axle mount I: thru axle 12×142 mm, Axle mount II: hub gear 135 mm, Brake: Postmount Disc 160, Tire clearance: 55 mm with plates, mudguard and luggage carrier eyelets BB Standard: Bosch, Press Fit |
|---|---|
| Fork | Suntour Mobie E25 LO, axle mount: thru axle 15×100 mm, steerer tube: 1 1/8in to 1.5in, travel: 75 mm, suspension: steel spring, damping adjustment: lockout, max. tire width: 55 mm, disc brake mount Travel: 75mm |
| Bottom Bracket | Bosch, press-fit |
| Stem | Speedlifter Stem Twist Pro, length: depending on frame height, fork shaft clamp : 28.6 mm, handlebar clamp : 31.8 mm, angle adjustable, can be swiveled sideways without tools |
| Saddle | Selle Italia Garda Gel, gel/elastomer padding |
| Seatpost | Suntour SP12-NCX, parallelogram suspension seat post, medium spring hardness, durable stainless steel bushings, 50 mm travel, diameter: 31.6 mm Type: Suspension |
| Pedals | TRENGA C016, Large, rubberized tread, aluminum pedal body, reflectors |
Groupset
| Crank | FSA CK-602, crank length: 172.5 mm, material: forged 6061/T6 aluminum, finish: black anodized, Q-factor: 187 mm |
|---|---|
| Shifters | Shimano Nexus SL-C7000 5-speed, ergonomic twist grip shift lever, easy-to-read optical gear display, smooth and easy operation |
| Brakes | Shimano Deore XT BR-T8100, hydraulic disc brake, high braking power with very good controllability, compatible with ICE-Tech pads, brake lever: BL-T8100 3-finger, brake calliper: BR-M8100 2-piston, brake pad: G05A-RX Resin Type: Shimano XT Hydraulic Disc |
Wheels
| Rims | Ryde Andra 321, light and stable, ideal for modern e-bikes, 36 hole, ETRTO: 21-622 |
|---|---|
| Tires | Schwalbe Marathon E-Plus Reflex, Size: 50-622, Especially for e-bikes, Grippy, durable ADDIX-E compound, Puncture-proof thanks to Smart DualGuard, Reflective strips |
Electric Components
| Motor | Bosch Performance Line Cruise, Almost silent, Max. torque: 75 Newton meters, Rated continuous power: 250 W, Max. power at 70 rpm: 550 W, Automatic adjustment of support |
|---|---|
| Battery | Bosch Powertube 500 BES3, protected integrated in the down tube, voltage: 36V, capacity: 13.4 Ah, energy content: approx. 500Wh, weight: approx. 3 kg |
| Display | Bosch Kiox 300, navigation function, activity tracking – saves tour and fitness data, regular updates possible via FLOW app, push assist function, e-bike lock function |
| Charger | Bosch 4A Charger, charging current (max.): 4 A, battery charging voltage: 36 V, size: 200 x 90 x 53 mm, weight: including cable approx. 700 grams, charging time: 4.5 h for PowerTube 500, approx. 4.9 h for PowerTube 625, approx. 3.5 h for PowerPack 400 |
Accessories
| Lights | Front: Busch & Mller Lumotec IQ-X E-Bike, 150 Lux, large area light field, daytime running light, close-range illumination, aluminum housing, Rear: Busch & Mller Toplight Line, LED rear light, LINE-TEC for large-area visibility, parking light, integrated Z-large area reflector |
|---|---|
| Fenders | SKS Bluemels matt black, sandwich construction made of aluminum/plastic, robust, rigid and corrosion-resistant, innovative light cable routing system, ASR safety system, width: 60 mm, max. tire width: 50 mm |
| Racks | Racktime Stand-It, SNAPIT compatible, load capacity: 25 kg, spring clamp can be easily retrofitted, material: aluminum |
| Lock | Abus X-PLUS battery lock, robust X-PLUS lock for Bosch Powertube BES3 |
