Build
| Frame | Aluminium 6061 TFW, Motor mount: Bosch, Cable routing: partially integrated, Axle mount I: thru axle 12×142 mm, Axle mount II: hub gear 135 mm, Brake: Postmount Disc 160, Tire clearance: 55 mm with plates, mudguard and luggage carrier eyelets BB Standard: Bosch, Press Fit |
|---|---|
| Fork | Suntour Mobie E25 LO, axle mount: thru axle 15×100 mm, steerer tube: 1 1/8in to 1.5in, travel: 75 mm, suspension: steel spring, damping adjustment: lockout, max. tire width: 55 mm, disc brake mount Travel: 75mm |
| Bottom Bracket | Bosch, press-fit |
| Stem | TRENGA Aluminium Angle adjustable, length: depending on frame height, fork stem clamp : 28.6 mm, handlebar clamp : 31.6 mm |
| Saddle | Selle Italia Garda Gel, gel/elastomer padding |
| Seatpost | TRENGA aluminum rigid, diameter: 31.6 mm, length: 400 mm, clamping: 2-way, offset: 10 mm Type: Rigid |
| Pedals | TRENGA C016, Large, rubberized tread, aluminum pedal body, reflectors |
Groupset
| Crank | FSA CK-602, crank length: 172.5 mm, material: forged 6061/T6 aluminum, finish: black anodized, Q-factor: 187 mm |
|---|---|
| Shifters | Shimano Nexus SL-C6000 Revo 8-speed, optical gear display, smooth twist grip shifting, precise shifting feel |
| Chain | Shimano CN-HG71, 6,7,8-speed compatible, HYPERGLIDE, e-bike compatible |
| Chain Guide | SKS Chainblade-E Bosch, Material: plastic, Stable and lightweight, Designed for hub gears |
| Brakes | Shimano BR-MT402, hydraulic disc brake, reliable brake control, brake lever: BL-MT402 3-finger, brake calliper: BR-MT410 2-piston, brake pad: B05S-RX Resin Type: Shimano Deore Hydraulic Disc |
Wheels
| Rims | Ryde Andra 321, light and stable, ideal for modern e-bikes, 36 hole, ETRTO: 21-622 |
|---|---|
| Tires | Schwalbe Marathon E-Plus Reflex, Size: 50-622, Especially for e-bikes, Grippy, durable ADDIX-E compound, Puncture-proof thanks to Smart DualGuard, Reflective strips |
Electric Components
| Motor | Bosch Active Line Plus Smart System, The quietest drive unit in the Bosch portfolio, Max. torque: 50 Newton meters, Rated continuous power: 250 W, Max. power at 70 rpm: 370 W, Automatic support adjustment |
|---|---|
| Battery | Bosch Powertube 500 BES3, protected integrated in the down tube, voltage: 36V, capacity: 13.4 Ah, energy content: approx. 500Wh, weight: approx. 3 kg |
| Display | Bosch Intuvia 100, Clear and well-arranged display, Intuitive and easy to use, Optical gear shift support, Fully networked and regularly updated, E-bike lock theft protection possible |
| Charger | Bosch 4A Charger, charging current (max.): 4 A, battery charging voltage: 36 V, size: 200 x 90 x 53 mm, weight: including cable approx. 700 grams, charging time: 4.5 h for PowerTube 500, approx. 4.9 h for PowerTube 625, approx. 3.5 h for PowerPack 400 |
Accessories
| Lights | Rear: Busch & Mller Toplight 2-C, LED rear light for luggage carrier mounting, LINE-TEC light clamps, integrated Z-large area reflector |
|---|---|
| Fenders | SKS Bluemels matt black, sandwich construction made of aluminum/plastic, robust, rigid and corrosion-resistant, innovative light cable routing system, ASR safety system, width: 60 mm, max. tire width: 50 mm |
| Racks | Racktime Stand-It, SNAPIT compatible, load capacity: 25 kg, spring clamp can be easily retrofitted, material: aluminum |
| Lock | Abus X-PLUS battery lock, robust X-PLUS lock for Bosch Powertube BES3 |
| Stand | Hebie rear triangle 661, material: steel, coated, wide base for secure stand, load capacity up to 25 kg, stepless length adjustment without tools, dropout direct mounting KSA 40 |
| Bell | TRENGA Single Bell, Material: Aluminium, Bell clapper rotatable, Loud and sonorous |
