Description

Build

Frame

Aluminium 6061 TFW, Motor mount: Bosch, Cable routing: partially integrated, Axle mount I: thru axle 12×142 mm, Axle mount II: hub gear 135 mm, Brake: Postmount Disc, Tire clearance: 55 mm with plates, mudguard and luggage carrier eyelets

BB Standard: Bosch, Press Fit

Fork

Suntour Mobie E25 LO, axle mount: thru axle 15×100 mm, steerer tube: 1 1/8in to 1.5in, travel: 75 mm, suspension: steel spring, damping adjustment: lockout, max. tire width: 55 mm, disc brake mount

Travel: 75mm

Bottom Bracket

Bosch, press-fit

Stem

TRENGA aluminum rigid, length: depending on frame height, fork clamp : 28.6 mm, handlebar clamp : 31.8 mm, angle: 17

Handlebar

TRENGA, width: 620 mm, handlebar clamp : 31.8 mm, backsweep: 25

Saddle

Selle Italia T-3 Flow City, Comfortable, wide city and touring saddle, Large FLOW opening relieves the perineal area, Gel padding with Soft-Tek cover, Hi-Viz inserts increase visibility in the dark

Seatpost

TRENGA aluminium rigid, diameter: 29.8 mm, length: 350 mm, clamping: 2-way, offset: 0 mm

Type: Rigid

Pedals

TRENGA C016, Large, rubberized tread, aluminum pedal body, reflectors

Groupset

Rear Derailleur

Shimano Deore RD-M5130 SGS, Shadow RD Plus design for optimal chain guidance, Optimized for LINKGLIDE, Smooth and reliable shifting, Stabilizer reduces chain slap, Largest pinion max. 43 teeth

Crank

FSA CK-602, crank length: 172.5 mm, material: forged 6061/T6 aluminum, finish: black anodized, Q-factor: 187 mm

Shifters

Shimano Deore SL-M5130, Rapidfire Plus – smooth, fast shifting, variable I-SPEC EV mounting, optical gear display, 2-way release allows shifting with thumb or index finger

Cassette

Shimano CS-LG400-10, 10-speed LINKGLIDE, gradation: 11-13-15-17-20-23-26-30-36-43, increased wear resistance

Chain

Shimano CN-E8000, HG-X for E-Bike, Optimized shifting behavior, Dirt-repellent design, SIL-TEC treatment for better durability

Brakes

Shimano Deore BR-T6000, hydraulic disc brake, powerful, predictable braking performance, compatible with ICE-Tech pads, brake lever: BL-T6000 3-finger, brake calliper: BR-M6000 2-piston, brake pad: G05A-RX Resin

Type: Shimano Deore Hydraulic Disc

Wheels

Rims

Ryde Andra 321, light and stable, ideal for modern e-bikes, 36 hole, ETRTO: 21-622

Tires

Schwalbe Marathon E-Plus Reflex, Size: 55-622, Especially for e-bikes, Grippy, durable ADDIX-E compound, Puncture-proof thanks to Smart DualGuard, Reflective strips

Electric Components

Motor

Bosch Performance Line Cruise, Almost silent, Max. torque: 75 Newton meters, Rated continuous power: 250 W, Max. power at 70 rpm: 550 W, Automatic adjustment of support

Battery

Bosch Powertube 500 BES3, protected integrated in the down tube, voltage: 36V, capacity: 13.4 Ah, energy content: approx. 500Wh, weight: approx. 3 kg

Display

Bosch Intuvia 100, Clear and well-arranged display, Intuitive and easy to use, Optical gear shift support, Fully networked and regularly updated, E-bike lock theft protection possible

Charger

Bosch 4A Charger, charging current (max.): 4 A, battery charging voltage: 36 V, size: 200 x 90 x 53 mm, weight: including cable approx. 700 grams, charging time: 4.5 h for PowerTube 500, approx. 4.9 h for PowerTube 625, approx. 3.5 h for PowerPack 400

Accessories

Lights

Rear: Busch & Mller Toplight Line E Brex, brake and emergency brake light function, super bright with high visibility, sensor technology: no connection to the brake required, integrated Z-large area reflector, Busch & Mller Toplight Dart Brex, LED rear light for e-bikes, brake and emergency brake light function, integrated Z-large area reflector

Fenders

SKS Evo ALU 65mm, Made of high-quality aluminum, Robust and rigid, Innovative light cable routing system, ESC safety system, Width: 65 mm, Max. tire width: 60 mm

Racks

Racktime Stand-It, SNAPIT compatible, load capacity: 25 kg, spring clamp can be easily retrofitted, material: aluminum

Lock

Abus X-PLUS battery lock, robust X-PLUS lock for Bosch Powertube BES3

Stand

Hebie rear triangle 663, material: steel, coated, wide base for secure stand, load capacity up to 25 kg, stepless length adjustment without tools, dropout direct mounting KSA 18

Bell

TRENGA Single Bell, Material: Aluminium, Bell clapper rotatable, Loud and sonorous
