Build
Frame |
E-Sommet 6061-T6 Double Butted Alloy, Internal cable routing, post mount disc brake mounts, Boost hub spacing – 148mm x 12mm thru axle, Shimano STEPS compatible. Axle Specifications: 180mm Length, 13mm Thread Length, M12xP1.0 Thread Pitch Tire Clearance:Â 2.5in Color:Â Octane Red – Black |
---|---|
Fork |
RockShox Domain R 29in, 170mm travel, DebonAir, 38mm stanchions, 110mm x 15mm Maxle Stealth axle, 44mm offset Travel:Â 170mm Spring Type:Â Air |
Shock |
RockShox Super Deluxe Select R, DebonAir, 205mm x 65mm, trunnion Travel:Â 167mm |
Bottom Bracket |
N/A, N/A |
Headset |
Nukeproof, ZS56/28.6 upper & ZS66/46 lower to suit 1-1/8in upper tapered to 1.8in lower headtube |
Stem |
Nukeproof Neutron AM, 6061 Alloy, 45mm length, 31.8mm Handlebar Clamp Diameter, 0 Rise |
Handlebar |
Nukeproof Horizon V2 Riser, 7075 Alloy, 9 Back Sweep, 31.8mm Clamp Diameter, S & M: 780mm Wide, 12mm Rise, L & XL: 800mm Wide, 25mm Rise |
Saddle |
Nukeproof Trail Saddle, Black, Steel Rails |
Seatpost |
Brand-X Ascend Dropper, Remote lever, 31.6mm Diameter, S: 125mm drop, M: 150mm drop, L & XL: 170mm drop Type:Â Dropper |
Grips |
Vitus Lock On, N/A |
Groupset
Rear Derailleur |
Shimano Deore M5100, 11 Speed, Shadow Plus, Long Cage |
---|---|
Front Derailleur |
N/A, N/A |
Crank |
E*Thirteen E*Spec Plus, 34T Narrow Wide Chainring, 165mm Crank Length, 53mm Chain Line |
Shifters |
Shimano Deore M5100, 11 Speed, Rapidfire Plus |
Cassette |
Sunrace CSMS7, 11 Speed, 11-51T Range |
Chain |
KMC e11S, 11 Speed, E-Bike specific, 118 Links |
Brakes |
SRAM DB8, Post Mount, Four Piston Caliper Type:Â SRAM DB8 Hydraulic Disc |
Wheels
Rims |
Front: WTB ST Light i30 TCS 2.0, 29in, 32H, Presta Valve, Tubeless Ready Rim Tape Installed, Rear: WTB ST Light i30 TCS 2.0, 27.5in, 32H, Presta Valve, Tubeless Ready Rim Tape Installed |
---|---|
Front Hub |
Vitus KT DHF112, 32H, 6 Bolt Disc Fitment, 110mm x 15mm |
Rear Hub |
Vitus KT H5ER-SH, 32H, 6 Bolt Disc Fitment, HG Freehub, 148mm x 12mm |
Tires |
Front: Maxxis Assegai, 29in x 2.5in WT, 3C MaxxGrip compound, DD casing, Rear: Maxxis High Roller II, 27.5in x 2.5in WT, 3C MaxxTerra compound, DD casing |
Disc Rotors |
SRAM CenterLine, 200mm Front & Rear, 6 Bolt Hub Fitment |
Electric Components
Motor |
Shimano BT-EN806-A, 630Wh, Downtube Integrated |
---|---|
Battery |
Shimano BT-EN806-A, 630Wh, Downtube Integrated |
Display |
Shimano EM800, Boost, Trail, Eco, Off & Walk modes |
