Build
Frame |
6061 alloy, hydroformed T6 aluminium, multi-butted, custom drawn, tapered headtube, internal cable routing, Shape.it Link and 12mm x 148mm Boost dropouts Hanger Standard:Â UDH |
---|---|
Fork |
Fox Float 38 Performance, 160mm travel, 44mm offset with Grip damper, three-position adjustable, tapered steerer, 110mm x 15mm Boost, E-thru-axle Travel:Â 160mm Spring Type:Â Air |
Shock |
Fox Float Performance DPS, EVOL LV, custom tuned for Whyte, three position adjustable compression and rebound damping |
Bottom Bracket |
N/A |
Headset |
FSA No. 55/35 Orbit 1.5 ZS, 1.8in lower and 1 1/8in upper sealed cartridge bearings |
Stem |
Whyte Enduro, 35mm extension, 35mm bar bore |
Handlebar |
Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 780mm wide |
Saddle |
Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
Seatpost |
Crank Brothers HighLine 3, 30.9mm (sizes XS/S/M/L 150mm travel; size XL 170mm travel), Highline ball socket remote lever Type:Â Dropper |
Pedals |
None |
Grips |
Whyte Enduro lock-on |
Groupset
Rear Derailleur |
SRAM GX T-Type AXS, 12 speed |
---|---|
Front Derailleur |
N/A |
Crank |
Whyte, forged alloy, 155mm, direct mount 36T chainring |
Shifters |
SRAM AXS Pod, two button MMX, 12 speed |
Cassette |
SRAM XS-1275 Eagle, 10-52T, 12 speed |
Chain |
SRAM GX T-Type Eagle, 12 speed |
Brakes |
SRAM Code R, four piston hydraulic with sintered metal pads, 220mm diameter disc rotor Type:Â SRAM Code R Hydraulic Disc |
Brake Levers |
SRAM Code R, MMX |
Wheels
Rims |
WTB HTZ i30 TCS 2.0 System, asymmetric, sleeved joint, super tough construction, tubeless ready, 32 hole |
---|---|
Spokes |
DT Swiss New Champion 2.0mm, black stainless, brass nipples |
Front Hub |
Alloy, double sealed cartridge bearings, 15mm x 110mm Boost spacing, 32 hole |
Rear Hub |
Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole |
Tires |
Maxxis Assigai WT, TR, 2.5in 120TPI, EXO+ casing, 3C Maxx Grip, Dual Compound, Front; Maxxis Minion DHR II WT, TR, 2.4in 120TPI, Double Down, 3C Maxx Terra, Dual Compound, folding bead, rear |
Electric Components
Motor |
Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole |
---|
