Build
Frame |
Uni-directional carbon mainframe and seatstays, tapered head tube, ISCG 2 guide mounts, internal cable routing, Shape.it Link V2 and 12mm x 148mm Boost dropouts Hanger Standard:Â UDH |
---|---|
Fork |
Fox Float 34 Factory 29in, 140mm travel, 44mm offset, FIT4 damper, tapered steerer, 110mm x 15mm Boost Kabolt axle Travel:Â 140mm Spring Type:Â Air |
Shock |
Fox Float Factory, Evol LV, adjustable rebound and two position compression adjustment |
Bottom Bracket |
N/A |
Headset |
FSA No. 69/56/SRS, 1-1/8in upper and 1.5in lower with sealed angular contact bearing (ACB) catridge bearings, with side entry internal routing |
Stem |
Whyte Trail full CNC, 40mm extension, 35mm bar bore |
Handlebar |
Race Face NEXT R Carbon, 20mm rise, 35mm bar bore, 800mm wide |
Saddle |
Terra Aidon X1, 145mm, fibre reinforced nylon with Wingflex, Carbon 7x7mm rail |
Seatpost |
KS Lev Ci, 30.9mm, 175mm drop, with Southpaw remote lever Type:Â Dropper |
Pedals |
Fibre reinforced composite platform |
Grips |
Whyte Enduro lock-on |
Groupset
Rear Derailleur |
SRAM XX SL T-Type AXS, 12 speed |
---|---|
Front Derailleur |
N/A |
Crank |
SRAM XX Isis Carbon, 165mm arms, XX Gen4 Direct Mount 32T chainring, T-Type Light eMTB |
Shifters |
SRAM AXS Pod, right, MMX, 12 speed |
Cassette |
SRAM XS 1297, T-Type, 10-52T, 12 speed |
Chain |
SRAM XX T-Type, 12 speed |
Brakes |
SRAM Level Ultimate Stealth, four piston hydraulic, 180mm diameter disc rotor Type:Â SRAM Level Ultimate Stealth Hydraulic Disc |
Brake Levers |
SRAM Level Ultimate Stealth |
Wheels
Rims |
DT Swiss XRC 1501 Spline |
---|---|
Spokes |
DT Swiss Competition spokes straight pull (SP) |
Front Hub |
DT Swiss 240, straight pull, six bolt, 15mm x 110mm Boost spacing |
Rear Hub |
DT Swiss 240, e-bike specific, double sealed cartridge bearings, straight pull, 12mm x 148mm Boost spacing, six bolt, XD driver |
Tires |
Good Year Escape tubeless ready tan wall 29in x 2.4in, 800g front and rear |
Electric Components
Motor |
DT Swiss 240, e-bike specific, double sealed cartridge bearings, straight pull, 12mm x 148mm Boost spacing, six bolt, XD driver |
---|
