Build
Frame |
6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts, chain stay kick stand mount BB Standard:Â BSA, Threaded |
---|---|
Fork |
Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru-axle, Post Mount with single eyelets for mudguards |
Shock |
N/A |
Bottom Bracket |
Kynamic BSA, square taper, 122.5mm, with torque sensor |
Headset |
No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed catridge bearings and front entry for cables |
Stem |
N/A |
Handlebar |
Whyte one piece bar and stem: 50mm extension, 720mm width, 20mm rise, seven degree backsweep, four degree upsweep |
Saddle |
Whyte Custom |
Seatpost |
Whyte dropper post, 100mm drop Type:Â Dropper |
Pedals |
Fibre reinforced composite platform |
Grips |
Whyte Custom dual density lock-on |
Groupset
Rear Derailleur |
Shimano Cues 9 speed, Shadow Design and direct attachment |
---|---|
Front Derailleur |
N/A |
Crank |
Shimano Cues 9 speed, 170mm, 40T chainring, with chain guard |
Shifters |
Shimano Cues 9 speed Rapidfire |
Cassette |
Shimano Cues, 9 speed, 11-46T |
Chain |
Shimano Cues 9 speed |
Brakes |
Tektro T3020 hydraulic, 1.8mm thick 180mm diameter disc rotor Type:Â Tektro Hydraulic Disc |
Brake Levers |
Tektro T3020 Clean Sweep Design, three finger comfort lever |
Wheels
Rims |
WTB STp I27 rims, 32 hole |
---|---|
Spokes |
2.0mm, PG, black stainless, brass nipples |
Front Hub |
Alloy, double sealed cartridge bearings, 12mm x 100mm thru-axle, 32 hole |
Rear Hub |
Kynamic 250W, 36V, 45Nm 142mm power hub with replaceable freehub, 32 hole |
Tires |
Maxxis Reaver Tanwall 700 x 45c, EXO wire bead |
