Cannondale SuperX 2 Carbon Cyclocross Race Bike
The Cannondale SuperX 2 cyclocross bike is specified with a Shimano GRX Di2 12-speed drivetrain as the bike’s specified gearing configuration in this build.
- SuperX Carbon frame uses a 12x142mm thru-axle.
- Bike uses Shimano GRX 820 hydraulic disc brakes.
- Its Reserve 40|44 GR carbon rims are tubeless ready.
- Bike uses Vittoria Terreno T50 700x40c tires.
- A Shimano Di2 charger is included with the bike.
- Ready to Ride guarantee 100% Built.
- Safe International Doorstep Bike Shipping.
Description
Eliminate shifting lag on technical race circuits using the Cannondale SuperX 2, equipped with an electronic Shimano GRX Di2 2×12 groupset. The Proportional Response carbon frameset incorporates fully internal cable routing, flat mount disc calipers, and a Universal Derailleur Hanger. An aerodynamic Vision Trimax alloy handlebar connects to a C1 Conceal alloy stem above the 12 mm thru-axle carbon fork.
This build rolls on Reserve 40|44 GR carbon rims laced to DT Swiss 370 hubs with Vittoria Terreno T50 700x40c tires. The package includes Reserve Fillmore valves, a Shimano Di2 charger, and a Conceal stem computer mount, requiring riders to purchase pedals separately.
Key Specifications of the Cannondale SuperX 2 Cyclocross Bike
- The SuperX carbon frame features a 68 mm BSA threaded bottom bracket.
- A matching carbon fork uses a 12×100 mm thru-axle with Delta steerer.
- Electronic Shimano GRX 825 Di2 derailleurs control 2×12 shifting.
- A Shimano Ultegra R8100 12-speed cassette provides an 11-34T range.
- The Shimano GRX RX820 crankset features a 48/31 tooth chainring pairing.
- Shimano GRX 820 hydraulic brakes clamp dual 160 mm CL800 rotors.
- Reserve 40|44 GR carbon rims feature aero rim profiles.
- DT Swiss 370 rear hubs utilize the LN Ratchet drive system.
- Vittoria Terreno T50 700x40c tubeless tires provide wide-surface grip.
- A Cannondale C1 Aero 27 carbon seatpost offers SmartSense compatibility.
- A Prologo Dimension AGX T4.0 saddle sits atop the carbon post.
Who This Cyclocross Bike Fits
Racers who require tight cadence steps and double-chainring versatility benefit directly from this setup. The 48/31T chainrings and 11-34T cassette offer fine gear gradations for pacing on rolling courses and open straights. The 40c Vittoria tires deliver traction across mixed terrain while dampening track chatter.
Compatibility and Installation
Putting the bike into service involves mounting the wheels in the 12 mm thru-axles and connecting the Shimano Di2 charging cord to charge the internal battery. The frame features a 68 mm threaded BSA bottom bracket shell and a standard UDH rear dropout. Riders need to install standard 9/16-inch pedals.
Before Ordering the Cannondale SuperX 2 Cyclocross Bike
Review the crank length and handlebar width variations across sizes 46 cm through 61 cm before finalizing your order.
Cannondale SuperX 2 Specs
| Platform | SuperX |
| Model Name | SuperX 2 |
| Model Code | C17035U |
| Frame | SuperX Carbon, Proportional Response construction, internal cable routing, 12x142mm thru-axle, UDH, BSA 68mm threaded BB, flat mount disc, integrated seatpost binder |
| Fork | SuperX Carbon, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/2" Delta steerer, 55mm offset |
| Headset | Integrated, 1-1/8" - 1.5" |
| Rear Derailleur | Shimano GRX 825,>Integrated, 1-1/8" - 1.5" |
| Rear Derail Di2, Shadow RD+ | |
| Front Derailleur | Shimano GRX 825 Di2, braze-on |
| Shifters | Shimano GRX 825, Di2, 12-speed |
| Chain | Shimano M8100, 12-speed |
| Crank | Shimano GRX RX820, 48/31: 170mm (51cm), 172.5mm (54-56cm), 175mm (58-61cm). Size 46cm gets 165mm GRX RX610 cranks, 46/30 |
| Rear Cogs | Shimano Ultegra R8100, 11-34, 12-speed |
| Bottom Bracket | Shimano BSA 68 |
| Brakes | Shimano GRX 820, 160/160mm CL800 rotors |
| Brake Levers | Shimano GRX Di2 RX825 hydraulic disc |
| Rims | Reserve 40|44 GR, carbon, Turbulent Aero tech, 24h, tubeless ready |
| Spokes | Sapim CX-Delta J-bend |
| Tire Size | 40 |
| Wheel Size | 700c |
| Hubs | (F) DT Swiss 370, 12x100mm centerlock / (R) DT Swiss 370 LN Ratchet System, 12x142mm centerlock |
| Tires | Vittoria Terreno T50, 700x40c, tubeless ready |
| Front Tire | Vittoria Terreno T50, 700x40c |
| Rear Tire | Vittoria Terreno T50, 700x40c |
| Handlebar | Vision Trimax Aero Alloy: 400mm (46-51cm), 420mm (54-61cm) |
| Stem | Cannondale C1 Conceal, Alloy, 31.8, -6?: 90mm (46-51cm), 100mm (54-56cm), 110mm (58-61cm) |
| Grips | Cannondale Bar Tape, 3.5mm |
| Saddle | Prologo Dimension AGX T4.0 |
| Seatpost | Cannondale C1 Aero 27 Carbon, SmartSense compatible, 0mm offset (46cm), 15mm offset (51-61cm) |
| Extras | Reserve Fillmore valves, Shimano Di2 charger, Conceal Stem accessory/computer mount for Garmin/Wahoo |
| Manufacturer Warranty | Cannondale limited warranty covers frames, swing arms, chainstays, seatstays, full suspension shock links, and fork structure for the lifetime of the product. Paint, decals, and Cannondale branded components are covered for one year. |
Cannondale SuperX 2 Included:
- Cannondale stem faceplate computer and accessory mount bracket.
- Carbon seatpost assembly friction compound.
- Hydraulic disc brake pad transport spacers.
- Clear adhesive frame protection sticker set.
- Safety reflector set (front, rear, wheel) and standard warning bell.
- Tubeless valve stems and rim tape.
- Bicycle User Manual Book.
- Official Manufacturer Warranty Card.
Cannondale SuperX 2 General Questions
Q: Which groupset is installed on the Cannondale SuperX 2?
A: The Cannondale SuperX 2 is equipped with a Shimano GRX Di2 825 2x12-speed electronic groupset. It features a 48/31 crankset, 11-34 cassette, and GRX 820 hydraulic disc brakes. This 2x setup provides tighter gear progression and versatile range for high-speed road transitions and undulating gravel profiles.
Q: What is the tire clearance on Cannondale SuperX 2?
A: The Cannondale SuperX 2 offers massive tire clearance up to 48 mm in the rear and 51 mm in the fork. It ships with 700x40c Vittoria Terreno T50 tires. This wide spacing ensures debris clears easily during wet gravel rides and cyclocross mud sections without damaging the frame.
Q: How much does the complete Cannondale SuperX 2 weigh?
A: The complete Cannondale SuperX 2 weighs approximately 8.5 kilograms (18.7 pounds) in size 56. It combines an aerodynamic carbon frameset with Reserve 40|44 GR carbon wheels on DT Swiss 370 hubs. This balance provides impressive power transfer, high compliance, and aerodynamic speed on demanding off-road courses.
Q: What internal cable system does Cannondale SuperX 2 use?
A: The bike uses Cannondale's proprietary Delta Steerer system combined with a Conceal alloy stem. This setup routes brake hoses fully internally through the headtube without requiring oversized headtube bearings. It creates a sleek, low-drag frontal profile while preserving straightforward cockpit maintenance and stem adjustments.
